CPU INTEL CORE KABY LAKE I5-7400 3.0G BX80677I57400 6MB LGA1151 Box 64bit -Garanzia 3 anni-

> > SKU: BX80677I57400






Processor Number: i5-7400
Status: Launched
Launch Date: Q1’17
Lithography: 14 nm
# of Cores: 4
# of Threads: 4
Processor Base Frequency: 3.00 GHz
Max Turbo Frequency: 3.50 GHz
Cache: 6 MB SmartCache
Bus Speed: 8 GT/s DMI3
# of QPI Links: 0
TDP: 65 W
-Supplemental Information
Embedded Options Available : No
Conflict Free: Yes
Datasheet: Link
-Memory Specifications
Max Memory Size (dependent on memory type): 64 GB
Memory Types: DDR4-2133/2400, DDR3L-1333/1600 @ 1.35V
Max # of Memory Channels: 2
ECC Memory Supported ‡ : No
-Graphics Specifications
Processor Graphics ‡: Intel® HD Graphics 630
Graphics Base Frequency: 350.00 MHz
Graphics Max Dynamic Frequency: 1.00 GHz
Graphics Video Max Memory: 64 GB
4K Support: Yes, at 60Hz
Max Resolution (HDMI 1.4)‡: 4096×2304@24Hz
Max Resolution (DP)‡: 4096×2304@60Hz
Max Resolution (eDP – Integrated Flat Panel)‡: 4096×2304@60Hz
DirectX* Support: 12
OpenGL* Support: 4.4
Intel® Quick Sync Video : Yes
Intel® InTru™ 3D Technology: Yes
Intel® Clear Video HD Technology: Yes
Intel® Clear Video Technology: Yes
# of Displays Supported ‡: 3
Device ID: 0x5912
-Expansion Options
Scalability: 1S Only
PCI Express Revision: 3.0
PCI Express Configurations ‡: Up to 1×16, 2×8, 1×8+2×4
Max # of PCI Express Lanes: 16
-Package Specifications
Sockets Supported: FCLGA1151
Max CPU Configuration: 1
Thermal Solution Specification: PCG 2015C (65W)
Package Size: 37.5mm x 37.5mm
Low Halogen Options Available: See MDDS
-Advanced Technologies
Intel® Turbo Boost Technology ‡: 2.0
Intel® vPro Technology ‡ : No
Intel® Virtualization Technology (VT-x) ‡: Yes
Intel® Virtualization Technology for Directed I/O (VT-d) ‡ : Yes
Intel® TSX-NI: Yes
Intel® 64 ‡ : Yes
Instruction Set: 64-bit
Instruction Set Extensions: SSE4.1/4.2, AVX 2.0
Idle States: Yes
Enhanced Intel SpeedStep® Technology : Yes
Thermal Monitoring Technologies: Yes
Intel® Identity Protection Technology ‡: Yes
Intel® Stable Image Platform Program (SIPP): No
-Intel® Data Protection Technology
Intel® AES New Instructions : Yes
Secure Key: Yes
Intel® Software Guard Extensions (Intel® SGX): Yes
Intel® Memory Protection Extensions (Intel® MPX): Yes
-Intel® Platform Protection Technology
OS Guard: Yes
Execute Disable Bit ‡: Yes
Intel® Device Protection Technology with Boot Guard: Yes
